2008-2018 Pontiac Vibe, Toyota Corolla +1 More Front Right Rubber Brake Hose | AGS-KT30531
The AGS AGS-KT30531 is a premium rubber brake hydraulic hose engineered as a direct-fit replacement for 3 vehicle applications including the Pontiac Vibe and Toyota Corolla, Front Right position. Manufactured to OE specifications using DOT-approved and durable EPDM construction, this brake hose delivers reliable hydraulic performance, corrosion resistance, and a precise factory fit for confident installation.
Key Features & Benefits
- DOT-approved for road use and federal compliance
- EPDM hose construction for flexibility, durability, and chemical resistance
- Treated Steel fittings on both ends for corrosion resistance
- OE-quality replacement — direct fit with factory mounting points
- Each hose is 100% pressure tested for leaks
- Engineered to OEM hydraulic standards
- Backed by AGS quality assurance from a 70+ year automotive aftermarket leader
Vehicle Fitment
This brake hose is engineered to fit the following vehicle applications:
| Year | Make | Model | Submodel | Position |
|---|---|---|---|---|
| 2009 | Pontiac | Vibe | — | Front Right |
| 2010 | Pontiac | Vibe | — | Front Right |
| 2008 | Toyota | Corolla | — | Front Right |
| 2009 | Toyota | Corolla | — | Front Right |
| 2010 | Toyota | Corolla | — | Front Right |
| 2011 | Toyota | Corolla | — | Front Right |
| 2012 | Toyota | Corolla | — | Front Right |
| 2013 | Toyota | Corolla | — | Front Right |
| 2014 | Toyota | Corolla | — | Front Right |
| 2015 | Toyota | Corolla | — | Front Right |
| 2016 | Toyota | Corolla | — | Front Right |
| 2017 | Toyota | Corolla | — | Front Right |
| 2018 | Toyota | Corolla | — | Front Right |
| 2008 | Toyota | Matrix | — | Front Right |
| 2009 | Toyota | Matrix | — | Front Right |
| 2010 | Toyota | Matrix | — | Front Right |
| 2011 | Toyota | Matrix | — | Front Right |
| 2012 | Toyota | Matrix | — | Front Right |
| 2013 | Toyota | Matrix | — | Front Right |
| 2014 | Toyota | Matrix | — | Front Right |
Cross-Reference / Replaces These Part Numbers
The AGS-KT30531 is a direct cross-reference for the following replacement brake hose part numbers:
| Brand | Part Number |
|---|---|
| Dorman First Stop | H621099 |
| Raybestos | BH383326 |
| Sunsong | 2202987 |
| Wagner | BH143821 | F143821 |
| Centric Parts | 150.44149 |
| CARQUEST | BHA621099 |
| Alltech Automotive | 612975 |
| DFC Brake Hoses - Archived | 350-76105 |
| General Motors | 19184373 |
| Toyota | 9094702E76 | 9094702G77 | 90947A2025 | 90947A2075 | 90947A2077 |
Specifications
| Hose Material | EPDM |
|---|---|
| Outer Sleeve Material | EPDM |
| Inside Diameter (in) | 1/8 |
| Outside Diameter (mm) | 10.5 |
| Overall Length (mm) | 633 |
| Axis 1 Length (in) | 24.9375 |
| End 1 Fitting Material | Treated Steel |
| End 1 Fitting Type | Female |
| End 1 Thread Size (mm) | M10X1 |
| End 2 Fitting Material | Treated Steel |
| End 2 Fitting Type | Female |
| End 2 Thread Size (mm) | M10X1 |
| Crush Washers Included | No |
| Mounting Bracket Included | No |
| DOT Approved | Yes |
About AGS Company
AGS Company Automotive Solutions has been a trusted name in the automotive aftermarket for over 70 years, manufacturing high-quality brake, fluid, and lubrication products engineered in the USA. Every AGS rubber brake hose is designed to meet or exceed OE specifications, rigorously tested, and backed by industry-leading quality assurance. Choose AGS for confident installation, dependable performance, and long service life.
⚠ California Proposition 65 Warning: WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov
