2004-2015 Mazda 3 & 5 Front Rubber Brake Hose | AGS-KT40248
The AGS AGS-KT40248 is a premium rubber brake hydraulic hose engineered as a direct-fit replacement for the 2004-2013 Mazda 3 and 2006-2015 Mazda 5, Front position. Manufactured to OE specifications using DOT-approved and durable EPDM construction, this brake hose delivers reliable hydraulic performance, corrosion resistance, and a precise factory fit for confident installation.
Key Features & Benefits
- DOT-approved for road use and federal compliance
- EPDM hose construction for flexibility, durability, and chemical resistance
- Treated Steel fittings on both ends for corrosion resistance
- OE-quality replacement — direct fit with factory mounting points
- Each hose is 100% pressure tested for leaks
- Engineered to OEM hydraulic standards
- Backed by AGS quality assurance from a 70+ year automotive aftermarket leader
Vehicle Fitment
This brake hose is engineered to fit the following vehicle applications:
| Year | Make | Model | Submodel | Position |
|---|---|---|---|---|
| 2004 | Mazda | 3 | — | Front Right |
| 2004 | Mazda | 3 | — | Front Left |
| 2005 | Mazda | 3 | — | Front Left |
| 2005 | Mazda | 3 | — | Front Right |
| 2006 | Mazda | 3 | — | Front Right |
| 2006 | Mazda | 3 | — | Front Left |
| 2007 | Mazda | 3 | — | Front Left |
| 2007 | Mazda | 3 | — | Front Right |
| 2008 | Mazda | 3 | — | Front Left |
| 2008 | Mazda | 3 | — | Front Right |
| 2009 | Mazda | 3 | — | Front Right |
| 2009 | Mazda | 3 | — | Front Left |
| 2010 | Mazda | 3 | — | Front Left |
| 2010 | Mazda | 3 | — | Front Right |
| 2011 | Mazda | 3 | — | Front Right |
| 2011 | Mazda | 3 | — | Front Left |
| 2012 | Mazda | 3 | — | Front Left |
| 2012 | Mazda | 3 | — | Front Right |
| 2013 | Mazda | 3 | — | Front Left |
| 2013 | Mazda | 3 | — | Front Right |
| 2006 | Mazda | 5 | — | Front Left |
| 2006 | Mazda | 5 | — | Front Right |
| 2007 | Mazda | 5 | — | Front Left |
| 2007 | Mazda | 5 | — | Front Right |
| 2008 | Mazda | 5 | — | Front Left |
| 2008 | Mazda | 5 | — | Front Right |
| 2009 | Mazda | 5 | — | Front Left |
| 2009 | Mazda | 5 | — | Front Right |
| 2010 | Mazda | 5 | — | Front Left |
| 2010 | Mazda | 5 | — | Front Right |
| 2012 | Mazda | 5 | — | Front Left |
| 2012 | Mazda | 5 | — | Front Right |
| 2013 | Mazda | 5 | — | Front Left |
| 2013 | Mazda | 5 | — | Front Right |
| 2014 | Mazda | 5 | — | Front Left |
| 2014 | Mazda | 5 | — | Front Right |
| 2015 | Mazda | 5 | — | Front Left |
| 2015 | Mazda | 5 | — | Front Right |
Cross-Reference / Replaces These Part Numbers
The AGS-KT40248 is a direct cross-reference for the following replacement brake hose part numbers:
| Brand | Part Number |
|---|---|
| Dorman First Stop | H620685 |
| Raybestos | BH382663 |
| Sunsong | 2204672 |
| Wagner | BH141229 | F141229 |
| Centric Parts | 150.45040 |
| Bendix | 79179 |
| NAPA BRAKES | UP382663 |
| Alltech Automotive | 612546 |
| Coni-Seal | BH418420 |
| DFC Brake Hoses - Archived | 350-80032 |
| Mazda | BP4K43980D | BP4K43980F |
| Norflex | NF382663 |
Specifications
| Hose Material | EPDM |
|---|---|
| Outer Sleeve Material | EPDM |
| Outside Diameter (mm) | 10.5 |
| Overall Length (in) | 17.5 |
| Overall Length (mm) | 445 |
| Axis 1 Length (in) | 17.5 |
| End 1 Fitting Material | Treated Steel |
| End 1 Fitting Type | Male |
| End 1 Thread Size (mm) | M10x1 |
| End 2 Fitting Material | Treated Steel |
| End 2 Fitting Type | Female |
| Crush Washers Included | No |
| Mounting Bracket Included | No |
| DOT Approved | Yes |
About AGS Company
AGS Company Automotive Solutions has been a trusted name in the automotive aftermarket for over 70 years, manufacturing high-quality brake, fluid, and lubrication products engineered in the USA. Every AGS rubber brake hose is designed to meet or exceed OE specifications, rigorously tested, and backed by industry-leading quality assurance. Choose AGS for confident installation, dependable performance, and long service life.
