1991-1999 Multi-Vehicle Application Front Rubber Brake Hose | AGS-KT70260

The AGS AGS-KT70260 is a premium rubber brake hydraulic hose engineered as a direct-fit replacement for 8 vehicle applications including the Chevrolet Blazer and Chevrolet LLV, Front position. Manufactured to OE specifications using DOT-approved and durable EPDM construction, this brake hose delivers reliable hydraulic performance, corrosion resistance, and a precise factory fit for confident installation.

Key Features & Benefits

• DOT-approved for road use and federal compliance
• EPDM hose construction for flexibility, durability, and chemical resistance
• Treated Steel fittings on both ends for corrosion resistance
• OE-quality replacement — direct fit with factory mounting points
• Each hose is 100% pressure tested for leaks
• Engineered to OEM hydraulic standards
• Crush washers included for leak-free installation
• Backed by AGS quality assurance from a 70+ year automotive aftermarket leader

Vehicle Fitment

This brake hose is engineered to fit the following vehicle applications:

Year	Make	Model	Submodel	Position
1995	Chevrolet	Blazer	—	Front Left
1995	Chevrolet	Blazer	—	Front Right
1996	Chevrolet	Blazer	—	Front Left
1996	Chevrolet	Blazer	—	Front Right
1997	Chevrolet	Blazer	—	Front Left
1997	Chevrolet	Blazer	—	Front Right
1998	Chevrolet	Blazer	—	Front Right
1998	Chevrolet	Blazer	—	Front Left
1999	Chevrolet	Blazer	—	Front Left
1999	Chevrolet	Blazer	—	Front Right
1991	Chevrolet	LLV	—	Front Left
1991	Chevrolet	LLV	—	Front Right
1992	Chevrolet	LLV	—	Front Left
1992	Chevrolet	LLV	—	Front Right
1993	Chevrolet	LLV	—	Front Right
1993	Chevrolet	LLV	—	Front Left
1994	Chevrolet	LLV	—	Front Left
1994	Chevrolet	LLV	—	Front Right
1995	Chevrolet	LLV	—	Front Left
1995	Chevrolet	LLV	—	Front Right
1991	Chevrolet	S10	—	Front Left
1991	Chevrolet	S10	—	Front Right
1992	Chevrolet	S10	—	Front Right
1992	Chevrolet	S10	—	Front Left
1993	Chevrolet	S10	—	Front Right
1993	Chevrolet	S10	—	Front Left
1994	Chevrolet	S10	—	Front Left
1994	Chevrolet	S10	—	Front Right
1995	Chevrolet	S10	—	Front Left
1995	Chevrolet	S10	—	Front Right
1996	Chevrolet	S10	—	Front Right
1996	Chevrolet	S10	—	Front Left
1997	Chevrolet	S10	—	Front Right
1997	Chevrolet	S10	—	Front Left
1998	Chevrolet	S10	—	Front Left
1998	Chevrolet	S10	—	Front Right
1999	Chevrolet	S10	—	Front Right
1999	Chevrolet	S10	—	Front Left
1991	Chevrolet	S10 Blazer	—	Front Left
1991	Chevrolet	S10 Blazer	—	Front Right
1992	Chevrolet	S10 Blazer	—	Front Left
1992	Chevrolet	S10 Blazer	—	Front Right
1993	Chevrolet	S10 Blazer	—	Front Right
1993	Chevrolet	S10 Blazer	—	Front Left
1994	Chevrolet	S10 Blazer	—	Front Left
1994	Chevrolet	S10 Blazer	—	Front Right
1992	GMC	Jimmy	—	Front Right
1992	GMC	Jimmy	—	Front Left
1993	GMC	Jimmy	—	Front Right
1993	GMC	Jimmy	—	Front Left
1994	GMC	Jimmy	—	Front Left
1994	GMC	Jimmy	—	Front Right
1995	GMC	Jimmy	—	Front Left
1995	GMC	Jimmy	—	Front Right
1996	GMC	Jimmy	—	Front Right
1996	GMC	Jimmy	—	Front Left
1997	GMC	Jimmy	—	Front Left
1997	GMC	Jimmy	—	Front Right
1998	GMC	Jimmy	—	Front Left
1998	GMC	Jimmy	—	Front Right
1999	GMC	Jimmy	—	Front Left
1999	GMC	Jimmy	—	Front Right
1991	GMC	S15 Jimmy	—	Front Right
1991	GMC	S15 Jimmy	—	Front Left
1991	GMC	Sonoma	—	Front Left
1991	GMC	Sonoma	—	Front Right
1992	GMC	Sonoma	—	Front Right
1992	GMC	Sonoma	—	Front Left
1993	GMC	Sonoma	—	Front Right
1993	GMC	Sonoma	—	Front Left
1994	GMC	Sonoma	—	Front Right
1994	GMC	Sonoma	—	Front Left
1995	GMC	Sonoma	—	Front Left
1995	GMC	Sonoma	—	Front Right
1996	GMC	Sonoma	—	Front Right
1996	GMC	Sonoma	—	Front Left
1997	GMC	Sonoma	—	Front Right
1997	GMC	Sonoma	—	Front Left
1998	GMC	Sonoma	—	Front Right
1998	GMC	Sonoma	—	Front Left
1999	GMC	Sonoma	—	Front Left
1999	GMC	Sonoma	—	Front Right
1996	Isuzu	Hombre	—	Front Left
1996	Isuzu	Hombre	—	Front Right
1997	Isuzu	Hombre	—	Front Left
1997	Isuzu	Hombre	—	Front Right
1998	Isuzu	Hombre	—	Front Left
1998	Isuzu	Hombre	—	Front Right
1999	Isuzu	Hombre	—	Front Left
1999	Isuzu	Hombre	—	Front Right

**INTERCHANGEABLE**

Cross-Reference / Replaces These Part Numbers

The AGS-KT70260 is a direct cross-reference for the following replacement brake hose part numbers:

Brand	Part Number
Dorman First Stop	H380280
Raybestos	45380280 | BH380280 | BH38868
AC Delco	18J1111
Sunsong	2201074
Wagner	BH124596 | BH132325 | F124596 | F132325
Centric Parts	150.66055
Bendix	77852
NAPA BRAKES	UP380280
ARI	87-44055
Aimco	B916610
Alltech Automotive	610037
Autospecialty	HB-86055
Coni-Seal	BH177852
DFC Brake Hoses - Archived	350-47271
General Motors	17989770 | 18032822 | 22113473
Isuzu	8221134730
Norflex	NF380280

**END_INTERCHANGEABLE****SPECS**

Specifications

Hose Material	EPDM
Outer Sleeve Material	EPDM
Inside Diameter (in)	1/8
Outside Diameter (mm)	10.5
Overall Length (in)	12.28
Axis 1 Length (in)	11.63
End 1 Fitting Material	Treated Steel
End 1 Fitting Type	Banjo
End 1 Thread Size (mm)	10
End 2 Fitting Material	Treated Steel
End 2 Fitting Type	Female
Crush Washers Included	Yes
Mounting Bracket Included	No
DOT Approved	Yes

**END_SPECS**

About AGS Company

AGS Company Automotive Solutions has been a trusted name in the automotive aftermarket for over 70 years, manufacturing high-quality brake, fluid, and lubrication products engineered in the USA. Every AGS rubber brake hose is designed to meet or exceed OE specifications, rigorously tested, and backed by industry-leading quality assurance. Choose AGS for confident installation, dependable performance, and long service life.
